APC XB5 Botão de emergência 1NO+1NC 22mm cabeça de cogumelo 40mm vermelho sem inscrição rodar para desbloquear

The APC XB5 is a robust emergency stop push button designed for industrial safety applications. Part of the Harmony XB5 series, this mushroom-headed operator (40 mm diameter) provides a highly visible, unmarked red actuator that requires a turn-to-release action, ensuring compliance with ISO 13850 standards. With a compact 22 mm mounting diameter and a durable plastic bezel, it offers reliable emergency stop functionality in harsh environments.

Advantages

High reliability with slow-break contact operation and a mechanical durability of 3,000,000 cycles. The IP66, IP67, IP69, and IP69K ratings, along with NEMA 13 and 4X protection, make it suitable for washdown and dusty environments. Screw clamp terminals ensure secure and easy wiring.

Suitable for

• Industrial machinery emergency stop circuits
• Automation and control panels
• Food and beverage processing equipment
• Outdoor or wet location installations

Key specifications

• Product Range: Harmony XB5
• Product Type: Emergency Stop Push Button
• Head Type: Mushroom 40 mm
• Operator Profile: Red, Unmarked
• Operator Action: Turn to Release
• Contact Configuration: 1 NO + 1 NC
• Contacts Operation: Slow-break
• Mounting Diameter: 22 mm
• Bezel Material: Plastic (Dark Grey)
• Rated Operational Voltage (Ue): 600 V (AC/DC)
• Rated Operational Current (Ie): 10 A (Thermal)
• Mechanical Durability: 3,000,000 cycles
• Electrical Durability: 1,000,000 cycles (AC-15, DC-13)
• IP Degree of Protection: IP66, IP67, IP69, IP69K
• NEMA Degree of Protection: NEMA 13, NEMA 4X
• Ambient Air Temperature for Operation: -40…70 °C
• Standards: EN/IEC 60947-5-1, ISO 13850
• Connections: Screw Clamp Terminals
• Shock Resistance: 30 gn

Recommendations

For optimal safety, ensure the emergency stop button is easily accessible and clearly visible. Pair with APC XB5 series enclosures and accessories for a complete solution.
