Borne de parafuso Cimco 1,5-16 mm², 1 polo, cinzento, 690V, 76A (180960)

Electricians and panel builders use this Cimco screw clamp to join solid or stranded copper conductors from 1.5 to 16 mm² in junction boxes and control cabinets. The one-pole terminal block has a screw connection and a grey polyamide housing.

Key specifications

• Connection type: Screw terminal
• Number of poles: 1
• Conductor cross-section (flexible): 1.5 - 16 mm²
• Conductor cross-section (rigid): 1.5 - 16 mm²
• Rated voltage: 690 V AC
• Rated current: 76 A
• Housing material: Polyamide (PA)
• Conductor material: Brass
• Colour: Grey
• Mounting type: Free-standing / junction box
• Operating temperature: -25 °C to +85 °C
• Flammability class: UL94 V-2

Why choose it

The screw clamp accepts a wide range of conductor sizes, so one type covers many wiring tasks. The polyamide housing is resistant to heat and impact, and the brass conductor ensures low contact resistance.

Ideal use cases

• Connecting supply lines in distribution boards
• Wiring junction boxes in residential and commercial buildings
• Prototyping and repairs in control cabinets

Good to know

The clamp is designed for free-standing installation or inside junction boxes. It complies with IEC 60998 for connection devices.
