Broca helicoidal HSS-G AWTOOLS AW43775 10 mm DIN 338

Drilling precise holes in tough materials like steel, cast iron, and hard plastics demands a bit that stays sharp, centered, and accurate. The AWTOOLS AW43775 twist drill bit is engineered to meet that challenge head-on. With a 10 mm diameter and DIN 338 standard geometry, this HSS-G bit delivers clean, round holes with minimal effort, making it an indispensable tool for metalworkers, fabricators, and serious DIYers.

Who is it for

This drill bit is ideal for professionals and hobbyists who regularly work with metal, including machinists, mechanics, maintenance technicians, and metal artists. It's also suitable for drilling non-ferrous metals and hard plastics, offering versatility across a range of projects.

Main features

• High-speed steel (HSS) construction with ground finish for durability and sharpness
• 135° split point tip for self-centering and reduced walking
• Right-hand cutting direction for standard drilling applications
• Cylindrical shank with 10 mm diameter for secure chuck grip
• DIN 338 compliance ensures consistent dimensions and performance
• Bright (uncoated) surface for easy chip evacuation

Specifications

• Drill bit type: Twist drill bit (HSS-G)
• Standard: DIN 338
• Diameter: 10.0 mm
• Total length: 133 mm
• Working length: 87 mm
• Shank type: Cylindrical
• Shank diameter: 10.0 mm
• Material: High-speed steel (HSS)
• Point angle: 135°
• Point type: Split point (self-centering)
• Surface finish: Bright (uncoated)
• Manufacturing process: Ground
• Cutting direction: Right-hand
• Suitable materials: Steel, cast steel, cast iron, sintered iron, non-ferrous metals, hard plastics
• Tolerance: h8
• Packaging quantity: 1 piece

Tips

For best results, use a center punch to mark the drilling location, especially on hard metals. Apply cutting fluid to reduce heat and extend bit life. Use appropriate speeds: lower RPM for steel, higher for non-ferrous metals. Ensure the drill bit is securely tightened in the chuck to prevent slippage.
