Cabo de fibra ótica InfiniBand Microconnect FIB320001 1 m SC OM1 62,5 µm

The Microconnect FIB320001 InfiniBand fibre optic cable is a 1 m patch cord with SC connectors and OM1 multimode fibre (62.5/125 µm). It is designed for high-speed data transmission in networking environments such as data centres, telecom rooms and server racks, providing a standard-compliant connection for Ethernet, gigabit Ethernet and Fibre Channel applications.

Advantages

This OM1 fibre cable uses LSZH (Low Smoke Zero Halogen) jacket material and is manufactured to conform with IEC, EIA/TIA and Telcordia standards. The 62.5 µm core multimode design supports reliable short- to medium-distance links with minimal signal loss and simple installation using SC connectors. The 1 m length offers a compact jumper solution for rack-to-rack or equipment-to-equipment connections.

Suitable for

• Fast Ethernet and Gigabit Ethernet connections
• Fibre Channel links in SAN and storage networks
• InfiniBand interconnects in server farms and high-performance clusters
• Patch panels and cross-connects in data centres and telecom rooms

Key specifications

• Manufacturer: MicroConnect
• Model / MPN: FIB320001
• EAN: 7331990015266
• Length: 1 m
• Connector type: SC — SC
• Fibre type: OM1 multimode, 62.5/125 µm core/cladding
• Jacket: LSZH

How to use

Connect one SC connector to the source transceiver or patch panel port and the other SC connector to the target device transceiver or port. Ensure connectors and transceiver ports are clean and free of dust before mating to avoid signal degradation. Route the cable inside rack cable managers or trays, avoiding tight bends below the recommended bend radius and preventing mechanical strain on the fibre ends.

Recommendations

For reliable performance, clean SC endfaces with appropriate fibre cleaning tools before installation, keep the cable within its specified bend radius, and use LSZH cabling in enclosed or public spaces where low smoke and halogen-free materials are required.
