Cabo patch de fibra ótica Wentronic Goobay 59647 SC/APC para LC/UPC monomodo, OS2, 0,5 m, amarelo

Connect your FTTH modem or router directly to the optical network terminal with this 0.5 m single-mode OS2 patch cable. The SC/APC connector plugs into the wall outlet, while the LC/UPC end fits the SFP module of your home gateway. Its yellow LSZH jacket and ceramic ferrules ensure low insertion loss and high return loss for stable gigabit and 10G links.

Key specifications

• Fibre type: Single-mode OS2, 9/125 µm core/cladding
• Connectors: SC/APC (green) to LC/UPC (blue)
• Length: 0.5 m, simplex construction
• Insertion loss: ≤ 0.3 dB typical
• Return loss: ≥ 60 dB (SC/APC), ≥ 50 dB (LC/UPC)
• Jacket: LSZH, yellow, 3.0 mm diameter
• Operating temperature: -20°C to 70°C
• Minimum bend radius: 10 mm dynamic, 20 mm static

Why choose it

Precision-polished ceramic ferrules and APC/UPC end faces minimise back reflection, ensuring error-free transmission for triple-play services. The LSZH jacket emits low smoke and no halogens, making it safe for indoor use. Its short length reduces clutter behind entertainment units and network cabinets.

Ideal use cases

• FTTH installations connecting ONT to router or media converter
• Data centre patching between SC/APC and LC/UPC panels
• Telecom rooms and office fibre distribution
• Testing and temporary links in lab environments

Good to know

The cable is factory-terminated and tested, ready for immediate use. Keep bend radius above 20 mm during installation to avoid microbending losses. For outdoor or high-flex applications, consider a ruggedised alternative.
