Caixa para PC Thermaltake Core P3 TG Pro Midi Tower branco

The Thermaltake Core P3 TG Pro Snow is an open-frame Midi Tower PC case in white that supports Mini-ITX, Micro ATX, ATX and E-ATX motherboards. It features a 4 mm tempered glass side panel, a modular open-frame layout, rotational PCI-E slots and an additional fan bracket that accepts three 120/140 mm fans, a 360/420 mm radiator or a distro plate. Front I/O includes two USB 3.0 Type-A ports and one USB 3.2 Gen 2 Type-C port. Storage support includes up to four 3.5" HDDs or five 2.5" SSDs depending on configuration. The case accommodates CPU coolers up to 180 mm high, GPUs up to 450 mm (two-way placements, without reservoir) and PSUs up to 200 mm in length. The redesigned recessed motherboard-side compartment and an included GPU holder simplify installation of large graphics cards and improve stability.

Advantages

The Core P3 TG Pro Snow offers a fully modular, dismantlable design that facilitates custom builds and easy access during assembly. Its additional fan bracket and three-orientation placement (wall-mounted, vertical, horizontal) provide flexible cooling and display options. Rotational PCI-E slots and an attached GPU holder enable both vertical and horizontal GPU presentation while reducing sag. The 4 mm tempered glass gives a clear view of components without sacrificing durability, and modernized front I/O ensures convenient connectivity.

Suitable for

• Custom desktop builds with high-end graphics cards
• AIO or custom liquid-cooling setups (360 mm / 420 mm radiators)
• Showcase or wall-mounted systems with open-frame aesthetics
• Users who need flexible fan/radiator placement and modular assembly

Key specifications

• Form factor: Midi Tower, open-frame
• Supported motherboards: Mini-ITX, Micro ATX, ATX, E-ATX (12"x10.5")
• Fans supported: 120 mm / 140 mm (additional bracket for three fans)
• Radiator support: up to 360 mm / 420 mm (additional bracket)
• CPU cooler max height: 180 mm
• GPU max length: up to 450 mm (two-way placement, without reservoir)
• PSU max length: 200 mm
• Storage: up to four 3.5" HDD or five 2.5" SSD
• Side panel: 4 mm tempered glass
• I/O ports: 2× USB 3.0 Type-A, 1× USB 3.2 Gen 2 Type-C
• Material: tempered glass, SPCC
• Colour: White
• Weight: 12.5 kg

How to use

Plan your component layout before assembly, choosing the desired orientation (wall-mounted, vertical or horizontal). Install the motherboard compatible with the supported form factors, mount the power supply up to 200 mm, and fit storage drives in the available 3.5" or 2.5" bays. Use the additional fan bracket at the front or top if you require extra fans, a radiator or a distro plate. Attach the GPU using the rotational PCI‑E slots and secure it with the included GPU holder to prevent sag. Install cooling (air or AIO/custom liquid) within the specified radiator and cooler height limits and connect front I/O to the motherboard headers as instructed in the manual.

Recommendations

For best stability and cooling performance, verify GPU clearance and PSU length before finalizing component choices, mount radiators on the additional fan bracket or the recessed motherboard-side compartment where appropriate, and use the modular panels for easy cable routing and future upgrades.
