Carregador de bateria DJI CHX260-65 DC 5-20V 5A Preto

The DJI CHX260-65 Battery Charger is a compact DC charger for DJI camera drone batteries. Designed to operate from a 5–20V DC source at up to 5A, the charger restores a drone battery to full capacity in approximately 1.55 hours. When used together with a DJI Mavic 3 Battery Charging Hub and a 65W portable or car charger, the Hub can be expanded to charge up to three batteries sequentially, prioritizing batteries with higher remaining power first.

Advantages

The charger’s wide input range (5–20V DC) and 5A current support flexible power sources such as power banks and vehicle outlets, while its compact black design makes it convenient for portable and travel use. Integration with the Mavic 3 Battery Charging Hub allows charging of multiple batteries in sequence, improving charging efficiency by allocating power based on each battery’s remaining charge.

Suitable for

• Recharging batteries for DJI camera drones
• Field use with 65W portable chargers or car chargers
• Use together with DJI Mavic 3 Battery Charging Hub to charge multiple batteries

Key specifications

• Model: DJI CHX260-65
• Input voltage: 5–20V DC
• Input current: 5A
• Approximate full charge time: 1.55 hours
• Color: Black
• Manufacturer part number (MPN): 922984
• EAN: 6941565922984

How to use

Connect the charger to a compatible DC power source within the 5–20V range, such as a 65W portable charger or a vehicle socket using an appropriate adapter. Attach the battery to the charger according to DJI’s battery connection orientation. If using with a DJI Mavic 3 Battery Charging Hub, connect the hub to the 65W power source; the hub will manage sequential charging of up to three batteries, prioritizing those with higher remaining power.

Recommendations

Use a stable 65W-rated power supply or a vehicle power outlet and follow DJI battery handling guidelines. Avoid exposing the charger and batteries to extreme temperatures and inspect connectors before each use to ensure proper contact.
