Conjunto de patilhas de substituição para Ricoh D1054583 Reverse – peça de substituição D1054583/SPEC

Spare Gate Pawl Assembly compatible with Ricoh devices and intended as a replacement for the gate/latch component used in the D1054583 Reverse mechanism. This part restores the mechanical action that controls sheet reversing, feeding or locking movements in compatible Ricoh office equipment. It is designed for service and repair work where a degraded or broken pawl assembly is the cause of operational faults.

Advantages

The replacement gate pawl assembly provides accurate mechanical engagement and reliable movement control to correct reversing and feeding issues. It restores contact points and alignment within the reverse mechanism, reducing misfeeds and repeated faults caused by worn parts. The component is engineered to fit the original mechanism geometry and to meet the functional requirements of Ricoh service procedures.

Suitable for

• Servicing Ricoh multifunction devices with the D1054583 Reverse mechanism
• Repairing reversing, feeding or locking faults caused by worn pawl components
• Preventive maintenance to restore reliable sheet handling
• Workshop replacement during parts overhaul or mechanism refurbishment

Key specifications

• Function: gate/pawl assembly for reverse mechanism
• Material: durable molded engineering plastic (compatible with original mechanism)
• Compatibility: designed to match the form and fit of the original reverse mechanism components
• Mounting: replacement-ready with original attachment points and alignment features
• Operation: mechanical engagement for sheet feed, reverse and latch actions

How to use

Power off the device and follow the manufacturer's service manual to access the reverse mechanism. Remove the defective pawl assembly by releasing the specified fasteners and alignment pins, then position the replacement part in the original orientation. Reinstall retainers and verify that moving parts operate freely and align with adjacent components before reassembling the device. Perform a functionality check using the device's diagnostic or feed test routines to confirm proper reversing and feeding action.

Recommendations

Use basic hand tools consistent with Ricoh service procedures, avoid excessive force during installation, and inspect surrounding gears, springs and sensors for wear. Replace any additional worn parts to prevent rapid recurrence of symptoms and run a few test cycles after installation to ensure correct operation.
