Detetor de presença ORNO 360° IP65 2000W com 3 detetores PIR, branco

This ORNO presence sensor delivers 360° motion detection with a 2000W switching capacity, making it a robust solution for automatic lighting control in demanding environments. Its IP65-rated, UV-resistant polycarbonate housing ensures reliable operation both indoors and outdoors, while the triple PIR detector array provides wide coverage and high sensitivity.

Advantages

The sensor combines three internal PIR elements to achieve a full 360° detection angle, eliminating blind spots and reducing false triggers. With a maximum detection range of 12 metres at a 2.5 m mounting height, it covers large areas efficiently. The adjustable time delay (10 seconds to 15 minutes) and light sensitivity (3 to 2000 lux) allow precise customisation for different applications, from security lighting to energy-saving automation. Its robust IP65 rating protects against dust and water jets, ensuring long-term durability in outdoor or wash-down areas.

Suitable for

• Outdoor lighting control for building entrances, car parks, and walkways
• Indoor high-bay lighting in warehouses, factories, and sports halls
• Automatic switching of LED, fluorescent, and incandescent loads up to 2000W resistive
• Energy management in commercial and industrial facilities
• Security lighting activation in residential and public spaces

Key specifications

• Sensor type: PIR (Passive Infrared) presence sensor
• Detection angle: 360°
• Max load: 2000W resistive, 1000W LED/inductive
• IP rating: IP65
• Power supply: 220-240V AC, 50/60Hz
• Detection range: up to 12 m (at 2.5 m mounting height)
• Mounting height: 2.5 m - 6 m
• Adjustable time delay: 10 s ± 3 s to 15 min ± 2 min
• Adjustable light sensitivity: 3-2000 LUX
• Operating temperature: -20°C to +40°C
• Humidity: <93% RH
• Detection speed: 0.6-1.5 m/s
• Standby power consumption: <0.5W
• Installation: ceiling surface mount
• Material: UV-resistant polycarbonate
• Colour: white
• Number of detectors: 3

Recommendations

For optimal performance, install the sensor at a height between 2.5 and 6 metres and avoid direct sunlight or heat sources that may affect PIR accuracy. Use in conjunction with a contactor for loads exceeding the rated capacity. Regularly clean the lens to maintain detection sensitivity.
