Eaton M22PVLT30/FK11RGFIY1 Caixa de comando com interruptor rotativo, 3 posições com retenção, 1NO/1NC, IP66/IP67/IP69K 199351

This Eaton M22 series control station enclosure integrates a 3-position maintained selector switch with red, yellow, and green position markings, providing clear visual status indication in industrial environments. Its robust design ensures reliable operation in demanding conditions.

Highlights

• Selector switch with 3 maintained positions for stable control states
• Contact configuration: 1 normally open (NO) and 1 normally closed (NC)
• High ingress protection: IP66, IP67, IP69K
• Wide operating temperature range: -25°C to +70°C
• Panel mount with screw terminals for secure wiring

In daily use

The M22PVLT30/FK11RGFIY1 is built for industrial control panels where clear, tactile switching is essential. The maintained selector switch stays in the selected position, making it suitable for mode selection, speed control, or process step changes. The red, yellow, and green markings allow quick recognition of the active state, reducing operator error.

Full specifications

• Product type: Control station
• Series: Eaton M22
• Actuator type: Selector switch
• Number of positions: 3
• Operation mode: Maintained (latching)
• Contact configuration: 1 NO + 1 NC
• Actuator colors/markings: Red, yellow, green
• Ingress protection: IP66, IP67, IP69K
• NEMA protection rating: NEMA 4X, 13
• Rated insulation voltage (Ui): 500 V AC
• Rated impulse withstand voltage (Uimp): 6000 V
• Operating temperature range: -25 to +70 °C
• Storage temperature range: -40 to +80 °C
• Mounting type: Panel mount
• Housing material: High-grade plastic
• Terminal type: Screw terminals
• Standards: IEC/EN 60947-5-1, UL 508, CSA C22.2 No. 14

Final note

With its robust construction and clear position indication, this control station is a dependable choice for industrial automation and machine control applications.
