Kit de calhas de montagem em rack Cisco C9500-4PT-KIT

The Cisco C9500-4PT-KIT rack rail kit is a mounting solution engineered for use with Cisco Catalyst 9500 Series switches, providing secure attachment and stable support in standard 19-inch equipment racks. The kit is compatible with multiple Catalyst 9500 platform variants and is intended to simplify installation, maintain correct alignment, and protect the switch chassis while installed in data center, wiring closet, or enterprise rack environments.

Advantages

This rack rail kit offers a robust metal construction to ensure long-term durability and repeated reconfiguration capability. It enables precise rail alignment and secure fastening to standard rack frames, reducing vibration and preventing unintended movement. The design supports easy front-to-back access to the switch for cabling and maintenance tasks, and the kit components are sized to match the physical mounting points of compatible Catalyst 9500 switches.

Suitable for

• Mounting Cisco Catalyst 9500 Series switches in 19-inch server or network racks
• Enterprise wiring closets and branch office network cabinets
• Data center racks where stable, rack-mounted switching infrastructure is required
• Environments needing repeatable, secure hardware installations for high-availability networks

Key specifications

• Form factor: Rack-mount rail kit designed for 19-inch racks
• Compatibility: Designed for Cisco Catalyst 9500 Series switch models including 12Q, 24Q, 40X, and 16X variants
• Material: Durable metal construction for structural support and longevity
• Mounting method: Front and rear attachment points for secure fixation to rack rails
• Access: Allows front-to-back access for cabling and maintenance
• Weight support: Engineered to support the installed weight of compatible switches (refer to switch documentation for exact weight limits)

How to use

Unpack the rack rail kit and verify all components against the included parts list. Attach the rails to the switch chassis following the orientation markings and manufacturer guidance, then mount the assembled rail and switch into the 19-inch rack by securing the front and rear rail brackets to the rack uprights. Confirm that all fasteners are tightened to prevent movement and that the switch is level. Route power and network cabling with adequate clearance to maintain airflow and to facilitate future maintenance.

Recommendations

Install the rail kit in accordance with the switch installation guide and rack manufacturer instructions. Use appropriate rack screws and cage nuts sized for your rack, and verify rack load capacity before placing equipment. Ensure sufficient ventilation around the switch and avoid over-tightening fasteners to prevent damage to rack or chassis mounting points.
