Lâmpada de trabalho LED Osram ROUND WL VX80-WD, 10W, 12/24V, 800lm, 6000K, feixe largo, IP67, ECE R10, ficha DT, 80mm

On a dark construction site or a muddy off-road trail, the Osram ROUND WL VX80-WD delivers a bright, wide beam that cuts through the night. This compact 80mm LED work light is engineered for professionals and enthusiasts who need reliable illumination in harsh conditions. With a theoretical output of 800 lumens and a wide beam pattern, it floods the immediate area with crisp 6000K cool white light, making it easier to spot obstacles, read instruments, or work safely.

Key specifications

• Light type: LED work light with wide beam (WD)
• Luminous flux: 800 lm theoretical, 550 lm effective
• Colour temperature: 6000 K (cool white)
• Rated input power: 10 W
• Input voltage: 12/24 V (multivolt)
• IP rating: IP67 (dust-tight and protected against temporary immersion)
• EMC/EMI compliance: ECE R10
• Operating temperature range: -30 to 60 °C
• Number of LEDs: 6
• Connector type: DT connector
• Cable length: 450 mm
• Lifespan (L70/B50): 5000 h
• Mounting type: bracket mount (stainless steel)
• Housing material: aluminium
• Lens material: polycarbonate
• Product diameter: 80 mm
• Product depth: 57 mm

Why choose it

The VX80-WD is built to survive. Its aluminium housing and polycarbonate lens shrug off impacts and vibrations, while the IP67 rating means dust and water won't stop it. The multivolt 12/24V input makes it compatible with a wide range of vehicles and equipment, and the DT connector ensures a secure, weatherproof electrical connection. The wide beam pattern is ideal for close-range illumination, reducing eye strain and improving safety in work zones.

Ideal use cases

• Off-road driving and auxiliary lighting for trucks, ATVs, and agricultural machinery
• Work site illumination for construction, mining, and forestry equipment
• Marine and outdoor applications where a compact, durable light is needed
• Replacement or upgrade for existing round work lights with 80mm mounting

Good to know

The Osram ROUND WL VX80-WD comes with a stainless steel mounting bracket for easy installation. The 450mm cable gives you flexibility in positioning, and the DT connector is a standard in the automotive and heavy equipment industry, ensuring reliable power delivery. With a lifespan of 5000 hours (L70/B50), you can count on consistent performance over years of use. Note that the effective luminous flux is 550 lm, which accounts for thermal and optical losses in real-world conditions.
