Módulo LCD Sony A2170075A — painel de ecrã de 3 polegadas para dispositivos eletrónicos

Sony LCD Module A2170075A is a 3-inch display panel designed for integration into compatible electronic devices. The module offers a compact visual interface suitable for repair, replacement or custom projects where a small form-factor display is required. It is intended to provide clear image output and to match physical and electrical interfaces specified for devices that accept this size and type of module.

Advantages

This 3-inch Sony LCD module delivers a balance of compact dimensions and visual clarity appropriate for portable or space-constrained applications. As an original-brand component, it supports direct replacement in devices engineered for compatible modules and can reduce the need for mechanical or electrical adaptation during installation. The module’s standard connector and mounting footprint simplify integration into repair workflows and prototype builds.

Suitable for

• Repairing small consumer electronics such as portable media players and handheld instruments
• Replacing damaged screens in compatible industrial controllers or measurement devices
• Integrating into custom electronic projects and prototypes that require a 3-inch display
• Technical training and component-level refurbishment tasks

Key specifications

• Display size: 3 inches diagonal
• Panel type: TFT-LCD (active matrix)
• Image area: compact format suitable for small devices
• Typical interface: flat flex cable or similar connector for module integration
• Mounting: standard small-module footprint for direct installation in compatible housings
• Color capability: full-color display suitable for graphic and text output

How to use

Before installation, verify mechanical dimensions and electrical compatibility with the host device. Handle the module by its edges and avoid contact with the display surface and connector pads. Align the connector carefully with the host board socket and secure any mounting points to prevent movement. Power the device only after confirming supply voltages and signal connections match the module’s requirements. If replacing an existing module, transfer any required bezel or bracket parts to maintain proper fit and clearance.

Recommendations

Use appropriate electrostatic discharge (ESD) precautions during handling and installation. Test the display in a controlled setup before final assembly to confirm image output, backlight operation, and touch functionality if present. For long-term reliability, avoid exposure to excessive heat, moisture, or mechanical stress.
