Relé Panasonic CB1AP24 24V DC 20A unipolar contacto de fecho simples (1 contacto de fecho)

Panasonic CB1AP24 is a 24 V DC electromagnetic relay with one normally open contact rated for 20 A at 28 V DC. Designed for switching DC loads, this compact relay conforms to Panasonic's quality standards and is intended for integration into control panels, industrial equipment, and automation systems where a single high-current DC switch is required.

Advantages

The relay offers a high switching current capacity of 20 A, a single normally open contact for straightforward control logic, and a 24 V DC coil voltage compatible with common control circuits. Its compact construction simplifies panel mounting and wiring in tight spaces.

Suitable for

• Switching DC loads in control panels
• Industrial automation and machinery
• Power circuits requiring a 24 V control signal
• Replacement or repair of compatible Panasonic relay sockets

Key specifications

• Manufacturer: Panasonic
• Model (MPN): CB1AP24
• Coil voltage: 24 V DC
• Contact arrangement: 1 normally open (1 NO)
• Contact rating: 20 A at 28 V DC
• EAN: 2050000156069

How to use

Mount the relay in a compatible socket or on a PCB according to the manufacturer's pinout. Apply 24 V DC to the coil terminals to energize the relay and close the normally open contact, allowing current flow through the switched circuit up to the specified 20 A. De-energizing the coil opens the contact and interrupts the circuit. Follow standard wiring and safety practices when installing and servicing the relay.

Recommendations

Ensure the connected load does not exceed 20 A at 28 V DC and provide adequate protection such as fuses or circuit breakers. Use the relay within its rated ambient temperature and mounting conditions, and verify compatibility with relay sockets or holders before installation.
