Relé temporizador multifunções Finder 110-240V AC/DC, 16A, 19 funções, 2 CO, calha DIN 840202300000

19 selectable timing functions in one compact DIN-rail module, handling 16 A at 250 V AC. The Finder 84.02 series multifunction timer covers 0.05 s to 100 h across 7 scales, with two changeover contacts for flexible control.

Overview

The Finder 84.02.0.230.0000 is a multifunction timer relay for industrial automation and building control. It operates on 110-240 V AC/DC and provides 19 timing functions, including delay-on, delay-off, interval, pulse, and symmetrical recycler modes. Timing is set with rotary switches and a potentiometer, with LED indication for supply and relay status.

What stands out

• 19 selectable functions cover a wide range of timing tasks
• Wide supply voltage range 110-240 V AC/DC
• Two changeover contacts rated 16 A at 250 V AC
• Time range from 0.05 seconds to 100 hours
• DIN rail mounting for quick installation

Technical details

• Function type: Multifunction timer
• Number of functions: 19
• Supply voltage: 110-240 V AC/DC
• Output contacts: 2 changeover (CO)
• Contact rating (AC1): 16 A @ 250 V AC
• Contact material: AgCdO (silver cadmium oxide)
• Time setting range: 0.05 s to 100 h
• Time scales: 7 selectable scales
• Mounting type: 35 mm DIN rail
• Operating temperature: -20°C to +50°C
• Protection degree: IP20 (terminals), IP40 (front panel)
• Dielectric strength (supply/contacts): 2 kV AC
• Power consumption: 2.5 VA (AC), 1.5 W (DC)
• Indicators: LED (supply, relay status)
• Adjustment: Rotary switches and potentiometer
• Electrical life (at rated load): 100,000 cycles
• Mechanical life: 10,000,000 cycles

Our verdict

A versatile timer relay for demanding control applications. Its wide voltage range, high contact rating, and extensive function set make it a reliable choice for panel builders and maintenance engineers.
