Fresa de topo de metal duro RUKO ERB-HM VHM, 6 mm, 4 arestas, geometria de aresta de topo, corte à direita, sem revestimento

Precision milling in demanding materials requires a cutter that holds its edge and dimension. The RUKO ERB-HM solid carbide end mill with 6 mm cutting diameter and 4 flutes delivers clean, accurate profiles in general-purpose milling tasks. Its solid carbide construction provides the hardness needed for consistent performance, while the square end geometry produces flat-bottomed slots and sharp shoulders.

Who is it for

Machinists and metalworking professionals who need a reliable, uncoated carbide end mill for everyday milling operations. Suitable for use in CNC machining centers and conventional milling machines where a right-hand cut and h6 shank tolerance are required.

Main features

• Cutting diameter: 6.00 mm
• Shank diameter: 6 mm with h6 tolerance
• 4 flutes for balanced chip evacuation and finish
• Square end (flat end) for sharp corners and flat bottoms
• Right-hand cutting direction
• Uncoated solid carbide for sharp cutting edges
• Overall length: 57 mm
• Flute length: 19 mm

Specifications

• Tool type: Solid carbide end mill
• Brand series: ERB HM Series
• Cutting diameter (d1): 6.00 mm
• Shank diameter (d2): 6 mm
• Number of flutes (Z): 4
• Overall length (L1): 57 mm
• Flute length (L2): 19 mm
• Tool material: Solid carbide
• End type: Square end (flat end)
• Cutting direction: Right-hand cut
• Coating: Uncoated
• Shank tolerance: h6

Tips

Use appropriate speeds and feeds for solid carbide tooling to maximize tool life. Ensure proper workholding and coolant application for best results in steel and non-ferrous metals.
