RUKO Cone de bucha com cone Morse 2 haste e encaixe B16, DIN 238, aço liga retificado de precisão, 115 mm

Drill chuck arbor for mounting B16 taper drill chucks onto machine spindles with Morse Taper 2 (MK2). Precision ground from high-grade alloy tool steel for high concentricity and secure friction fit.

Advantages

High precision concentricity ensures smooth drilling. Durable alloy steel construction withstands industrial use. DIN 238 standard guarantees compatibility with common tooling.

Suitable for

• Drill chucks with B16 taper
• Machine spindles with Morse Taper 2 (MK2/MT2)
• Industrial and professional workshop applications

Key specifications

• Machine side taper: Morse Taper 2 (MK2 / MT2)
• Chuck side taper: B16
• Standard: DIN 238
• Material: High-grade alloy tool steel
• Finish: Precision ground
• Overall length: 115 mm
• Morse taper length (L2): 64 mm
• B16 taper length (L3): 30 mm
• Max diameter (MK2): 17.78 mm
• Max diameter (B16): 15.73 mm

Recommendations

Ensure tapers are clean and dry before assembly. Press firmly to seat the arbor and avoid overtightening.
