RUKO cone de mandril morse 3 para B16, aço para ferramentas temperado, DIN 238, 112 mm

Drill chuck arbor for mounting drill chucks with B16 taper onto machine spindles with Morse Taper 3 (MK3). Precision ground from hardened tool steel for high concentricity and secure taper fit.

Advantages

Hardened tool steel construction with black oxide finish for corrosion resistance. Precision ground tapers ensure accurate chuck alignment and smooth operation.

Suitable for

• Machine tools with MK3 spindle taper
• Drill chucks with B16 mount
• Industrial and workshop environments

Key specifications

• Shank type: Morse Taper 3 (MK3)
• Chuck mount taper: B16
• Standard: DIN 238
• Material: High-grade tool steel
• Hardness: Hardened
• Surface finish: Precision ground
• Overall length: 112 mm
• Shank taper max diameter (D1): 23.825 mm
• Chuck taper max diameter (D2): 15.8 mm
• Drive type: Tang drive
• Removal method: Drift key

Recommendations

Ensure both tapers are clean and free of burrs before assembly. Use a drift key for safe removal from the spindle.
