RUKO FRS-DIN8033-HM-TiAlN-Ø12,0mm fresa de haste VHM, 4 arestas, revestida a TiAlN, DIN 8033, 12mm de diâmetro de corte, 75mm de comprimento

Machining tough materials like steel, stainless steel, and cast iron demands a cutting tool that resists wear and maintains precision. This solid carbide end mill with TiAlN coating delivers high hardness and heat resistance, enabling reliable slotting, profiling, and finishing operations in demanding workshops.

Who is it for

CNC machinists, toolmakers, and metalworking professionals who need a durable, high-performance end mill for general-purpose milling in ferrous and non-ferrous metals.

Main features

• Solid carbide (VHM) construction for rigidity and long tool life.
• TiAlN coating with hardness above 3000 HV and working temperature up to 800°C.
• 4-flute design with 30° helix angle for efficient chip evacuation and smooth cutting.
• Center cutting capability allows plunge cutting and ramping.
• Precision ground to DIN 8033 with cutting diameter tolerance h6.
• Cylindrical shank (DIN 6535 HA) for secure clamping in standard collets.

Specifications

• Tool Type: End Mill
• Material: Solid Carbide (VHM)
• Coating: TiAlN (Titanium Aluminum Nitride)
• Standard: DIN 8033
• Cutting Diameter (d1): 12.0 mm
• Shank Diameter (d2): 12.0 mm
• Total Length (l1): 75 mm
• Cutting Length (l2): 26 mm
• Number of Flutes: 4
• Helix Angle: 30°
• Shank Type: Cylindrical (DIN 6535 HA)
• Cutting Edge Type: Center Cutting
• Tolerance (Cutting Diameter): h6
• Application: Steel, Stainless Steel, Cast Iron, Non-ferrous Metals
• Machining Type: Slotting, Profiling, Finishing
• Coolant Supply: External

Tips

Use appropriate cutting parameters and external coolant to maximize tool life. Ensure the tool holder provides sufficient clamping force for the 12 mm shank.
