RUKO FRS-DIN8033-HM-TiAlN-Ø12,0mm fresa de topo VHM, 4 arestas, revestida a TiAlN

Machinists and CNC operators rely on this RUKO solid carbide end mill for precise slotting, profiling, and contouring in steel, stainless steel, cast iron, and non-ferrous metals. The TiAlN coating withstands high temperatures, making it suitable for dry machining or with coolant.

Key specifications

• Tool Type: End Mill
• Material: Solid Carbide (HM)
• Standard: DIN 8033
• Coating: Titanium Aluminum Nitride (TiAlN)
• Cutting Diameter (d1): 12.0 mm
• Shank Diameter (d2): 12.0 mm
• Overall Length (l1): 83 mm
• Cutting Length (l2): 26 mm
• Number of Flutes: 4
• Helix Angle: 30°
• Shank Type: Cylindrical (HA)
• Application: Universal machining of steel, stainless steel, cast iron, non-ferrous metals
• Cutting Edge: Center Cutting
• Tolerance (Cutting Diameter): h10
• Tolerance (Shank Diameter): h6
• Coating Hardness: Approx. 3000 HV
• Max. Coating Temperature: Approx. 800 °C
• Manufacturing Process: Precision Ground
• Recommended Machining: Dry or with coolant

Why choose it

The solid carbide construction and TiAlN coating deliver high wear resistance and extended tool life, even in demanding materials. The 30° helix angle and center cutting design ensure efficient chip evacuation and plunge capability.

Ideal use cases

• CNC milling of steel and stainless steel components
• Machining cast iron parts
• Precision work in non-ferrous metals

Good to know

Precision ground for consistent performance. Suitable for both dry and wet machining.
