RUKO SMU-DIN382-M6x1.0mm-6k Cossinetes redondos, rosca métrica ISO M6 x 1,0 mm, HSS, perfil retificado, à direita

This RUKO round die stands out for its ground profile and 6k tolerance class, delivering precise, clean threads in steel, cast iron, and non-ferrous metals. Unlike basic cut dies, the SMU-DIN382-M6x1.0mm-6k is built for both manual and low-speed machine operation, making it a versatile choice for workshops that demand repeatable results.

Highlights

• Metric ISO thread M6 × 1.0 mm to DIN 382
• High-speed steel (HSS) with bright finish
• Ground profile with 3 cutting edges
• Tolerance class 6k for standard fit
• Right-hand cutting direction

In daily use

Mount the die in a suitable die stock and apply steady pressure with cutting oil. The 20 mm outer diameter and 7 mm thickness fit common holders, while the right-hand cut covers most general threading tasks. Suitable for materials up to 800 N/mm² tensile strength.

Full specifications

• Thread type: Metric ISO thread
• Nominal diameter: M6
• Pitch: 1.0 mm
• Standard: DIN 382
• Material: HSS
• Tolerance class: 6k
• Die type: Round die
• Cutting direction: Right-hand
• Outer diameter: 20 mm
• Thickness: 7 mm
• Application material group: Steel, cast iron, non-ferrous metals
• Recommended material hardness: Up to 800 N/mm²
• Surface treatment: Bright (uncoated)
• Manufacturing process: Ground profile
• Number of cutting edges: 3
• Suitable for: Manual and machine operation (low speed)
• Requires: Die stock (not included)
• Product series: Standard Line

Final note

A dependable M6 threading die for everyday use, backed by RUKO's precision manufacturing.
