Schneider Electric Dispositivo de Bloqueio para Disjuntores Acti 9 PLM

The Schneider Electric Padlock Device for Acti 9 PLM Miniature Circuit Breakers is a safety accessory designed to prevent unauthorized operation of the circuit breaker. It locks the breaker in the OFF position using an external padlock (not supplied), ensuring secure isolation during maintenance or emergency situations. This padlocking device is compatible with Schneider Electric Acti 9 PLM MCBs and is constructed from durable polyamide (PA6) material in a grey finish. It is suitable for indoor use and meets IP20 protection standards.

Advantages

Enhances safety by preventing accidental or unauthorized switching on of circuits. Easy to install on the front face of the circuit breaker. Robust polyamide construction ensures long-lasting performance. Compact design does not interfere with adjacent devices.

Suitable for

• Industrial and commercial electrical installations requiring lockout/tagout procedures
• Maintenance personnel needing to isolate circuits safely
• Facilities where multiple users require controlled access to electrical panels

Key specifications

• Product Type: Padlocking Device
• Compatibility: Schneider Electric Acti 9 PLM Miniature Circuit Breakers
• Function: Locks circuit breaker in OFF position
• Locking Mechanism: Requires external padlock (max shackle diameter 8 mm)
• Material: Polyamide (PA6)
• Colour: Grey
• Mounting: Front face of circuit breaker
• Range: Acti 9
• Standards: IEC 60947-2 (relevant for compatible circuit breakers)
• Degree of Protection: IP20
• Quantity per Set: 1
• Operating Temperature: -25 to 70 °C
• Storage Temperature: -40 to 85 °C

Recommendations

For optimal safety, always use a high-quality padlock with a shackle diameter up to 8 mm. Ensure the circuit breaker is in the OFF position before installing the padlock device. This accessory is an essential component for any lockout/tagout program in compliance with safety regulations.
