Switch PoLRE 2N NVT Phybridge com 2 adaptadores (8 portas, Long Reach Ethernet, PoE+)

The 2N NVT Phybridge PoLRE Switch (model 1120103) is a professional-grade, unmanaged switch designed for long-range Power over Ethernet (PoE) deployments. Utilizing Power over Long Reach Ethernet (PoLRE) technology, it delivers data and power over distances up to 365 meters (1,200 ft) using single-pair UTP cabling, making it ideal for IP surveillance, VoIP, access control, and Wi-Fi applications. This switch comes with two PhyLink adapters for flexible connectivity.

Advantages

Extends network reach beyond standard Ethernet limits without requiring additional infrastructure. Supports both PoE and PoE+ (IEEE 802.3af/at) with a maximum PoE budget of up to 150W (with optional power supply). Plug-and-play operation eliminates the need for complex configuration. Rugged design suitable for rack, wall, or shelf mounting.

Suitable for

• IP surveillance systems requiring long-distance camera placement
• VoIP deployments in large buildings or campuses
• Access control systems with distributed door controllers
• Wi-Fi access points in hard-to-reach areas

Key specifications

• 8 PoLRE ports (10/100BASE-T symmetrical)
• 2 uplink ports (10/100/1000BASE-T Gigabit Ethernet)
• PoE standard: IEEE 802.3af/at (PoE/PoE+)
• Maximum cable distance: 365 m (1,200 ft)
• Supported cable types: single-pair UTP (voice-grade, CAT3, CAT5e, CAT6)
• Power input: external 57V DC (power supply sold separately)
• Mounting: rack-mountable (1U), wall-mountable, shelf
• LED indicators: system, link/activity, PoE status
• Operating temperature: 0°C to 50°C (32°F to 122°F)
• Compliance: CE, FCC, RoHS, WEEE

Recommendations

For optimal performance, use with the 2N 150W power supply (sold separately) to achieve the full 150W PoE budget. Ensure cabling meets single-pair UTP specifications for maximum reach.
