ABB MS132-0.16 disjuntor de proteção de motor, 0,10-0,16 A, 3 polos, térmico-magnético, 100 kA, ligações por parafuso

Small motors in fans, pumps, conveyors, and machine tools need dependable protection against overloads and short circuits. The ABB MS132-0.16 manual motor starter provides exactly that, with a finely adjustable thermal release range of 0.10 to 0.16 A and a fixed magnetic trip at 2.2 A. This compact 3-pole device safeguards low-current motors in industrial and commercial applications, ensuring reliable operation and long service life.

Who is it for

Panel builders, maintenance technicians, and OEMs who need dependable protection for low-current motors will find this starter ideal. It suits applications requiring manual switching and overload protection up to 0.16 A, with compliance to IEC/EN 60947 standards for global acceptance.

Main features

• Thermal-magnetic trip unit with adjustable thermal release (0.10–0.16 A) and fixed magnetic release (2.2 A)
• High short-circuit breaking capacity: 100 kA at 400 V AC
• 3-pole design for three-phase motor protection
• Screw terminals for secure wiring
• DIN rail mounting for quick installation
• IP20 degree of protection for use in enclosed panels
• Wide ambient temperature range: -25 to +70 °C
• Long electrical and mechanical durability: 100,000 cycles each

Specifications

• Rated operational current (Ie): 0.10–0.16 A
• Rated operational voltage (Ue): 690 V AC
• Number of poles: 3
• Rated short-circuit breaking capacity (Ics) at 400 V AC: 100 kA
• Degree of protection: IP20
• Mounting type: DIN rail
• Terminal type: Screw terminals
• Standard: IEC/EN 60947-1, -2, -4-1
• Ambient operating temperature: -25 to +70 °C
• Electrical durability: 100,000 cycles
• Mechanical durability: 100,000 cycles
• Rated impulse withstand voltage (Uimp): 6 kV
• Pollution degree: 3

Tips

For optimal protection, set the thermal release to match the motor's full-load current. Always install inside an enclosure to maintain the IP20 rating. Use appropriate screwdrivers for terminal tightening to ensure reliable connections.
