ACT SD6520 Tomada de rede Cat6a prateada, 2 portas RJ45, totalmente blindada, montagem encastrada, compatível com 10G

Unlike standard Cat6 outlets that top out at 1 Gbps, the ACT SD6520 is a fully shielded Cat6a flush-mount network wall outlet built for 10-Gigabit Ethernet. Its silver finish and integrated dust flaps give it a clean, professional look while protecting the RJ45 ports from debris. With two ports and LSA+ terminals, it supports both TIA/EIA 568A and 568B wiring, making it a flexible choice for high-speed home or office networks.

Highlights

• Category 6a performance: supports up to 10GBASE-T and 500 MHz bandwidth
• Two RJ45 ports with integrated dust protection flaps
• Fully shielded (FTP/STP) metal housing for superior EMI resistance
• Flush-mount design fits standard 80 x 80 mm frames
• LSA+ (Krone type) IDC terminals for reliable, tool-free termination
• PoE and PoE+ support for powering devices like IP cameras and access points
• Silver colour complements modern interiors

In daily use

Installing the SD6520 is straightforward: the 45° cable entry angle reduces strain on the cable, and the clear colour-coded wiring diagram on the terminal block speeds up termination. Once mounted, the dust flaps keep the ports clean when not in use, while the shielded housing prevents crosstalk even in electrically noisy environments. Whether you're connecting a workstation, a smart TV, or a PoE-powered device, this outlet delivers consistent, high-speed connectivity.

Full specifications

• Product type: Network wall outlet
• Network standard: Category 6a (Cat6a)
• Number of ports: 2
• Connector type (front): RJ45
• Shielding: Fully shielded (FTP/STP)
• Mounting type: Flush-mount
• Colour: Silver
• Transmission speed: Up to 10 Gigabit Ethernet (10GBASE-T)
• Frequency bandwidth: Up to 500 MHz
• Internal connection type: LSA+ (Krone type) IDC terminals
• Wiring scheme: TIA/EIA 568A & 568B
• PoE support: Yes (PoE, PoE+)
• Cable entry angle: 45°
• Housing material: Plastic with metal shielding
• Dust protection: Integrated dust protection flaps
• Frame dimensions: 80 x 80 mm
• Installation depth: Approx. 30–40 mm
• Certifications: ISO/IEC 11801, EN 50173

Final note

For future-proof networking, the ACT SD6520 offers the performance and shielding needed for 10G Ethernet in a sleek, durable package.
