Adaptador coaxial TELEGÄRTNER ficha N macho para ficha FME macho, 50 Ohm, DC-6 GHz J01027C0020

With a frequency range up to 6 GHz and VSWR ≤ 1.25, this Telegärtner coaxial adapter delivers precise signal transfer for RF applications. It converts an N-Type male connector to an FME male connector in a straight body configuration, maintaining 50 Ohm impedance across the entire band.

Overview

The J01027C0020 is a coaxial RF adapter engineered for dependable performance. The nickel-plated brass body and gold-plated center contact ensure low contact resistance and long-term durability. PTFE insulation provides stable dielectric properties over an operating temperature range of -40 °C to +85 °C.

What stands out

• Wide frequency coverage: DC to 6 GHz with minimal insertion loss (≤ 0.1 dB).
• Excellent VSWR (≤ 1.25) for consistent signal integrity.
• Robust construction: brass body with nickel plating, gold-plated center contact.
• High insulation resistance (≥ 5 GΩ) and dielectric withstand voltage of 1000 Veff.

Technical details

• Connector A: N-Type male
• Connector B: FME male
• Impedance: 50 Ohm
• Frequency range: DC - 6 GHz
• VSWR: ≤ 1.25
• Insertion loss: ≤ 0.1 dB
• Body material: Brass, nickel plated
• Center contact material: Brass, gold plated
• Insulator material: PTFE
• Operating temperature: -40 °C to +85 °C
• Configuration: Straight

Our verdict

A precision adapter for professionals needing reliable N-to-FME conversion in demanding RF environments.
