Adaptador VGA interno Gembird placa de interface série DB9

Internal VGA Adapter Gembird DB9 Serial Port Interface Card is an internal flat cable assembly that connects a motherboard serial port (IDC 10‑pin) to a DB9M connector mounted on a metal bracket. The adapter provides a VGA output interface via the DB9 serial port wiring and is designed for compact installation inside standard PC chassis with the listed dimensions.

Advantages

This internal adapter offers a simple way to bring a DB9M serial‑style connector to a computer rear panel using an IDC 10‑pin header. Its metal bracket ensures secure mounting and alignment with the chassis, while the compact size (85 × 120 × 25 mm) makes it suitable for most desktop systems. The product is labeled under the GEMBIRD brand and carries the manufacturer part number CCDB9RECEPTACLE.

Suitable for

• Adding a DB9M serial connector to a motherboard with an IDC 10‑pin serial header
• Connecting legacy serial devices or VGA displays routed via DB9 wiring in controlled installations
• Internal PC installations where a rear‑panel DB9 connector is required

Key specifications

• Brand: GEMBIRD
• Manufacturer part number (MPN): CCDB9RECEPTACLE
• Host interface: Serial (IDC 10‑pin)
• Output interface: DB9M (metal bracket) providing VGA signal wiring
• Internal: Yes
• Adapter dimensions (W × D × H): 85 × 120 × 25 mm
• Package dimensions (W × D × H): 310 × 400 × 180 mm

How to use

Install the adapter by connecting the IDC 10‑pin flat cable to the corresponding serial header on the motherboard, ensuring correct pin orientation. Secure the metal bracket into an available rear slot on the PC chassis so the DB9M connector is externally accessible. Connect the external DB9 cable or device to the DB9M connector. Verify connections before powering the system.

Recommendations

Use only with compatible motherboard serial headers and cabling. Confirm pinout compatibility between the motherboard header and the connected device; adaptors or wiring changes may be required for non‑standard pinouts. Handle the IDC connector carefully to avoid bent pins and ensure the metal bracket is firmly fastened to prevent connector stress.
