ALLNET ALL-NS1003 Switch de rede Gigabit Ethernet de 3 portas não gerido, sem ventoinha, caixa metálica

The ALLNET ALL-NS1003 is a compact, unmanaged network switch designed to expand your wired network with three Gigabit Ethernet ports. Its fanless design ensures silent operation, making it ideal for noise-sensitive environments like home offices or small businesses. The metal housing provides durability and efficient heat dissipation, while plug-and-play installation requires no configuration.

Advantages

Silent operation thanks to fanless design; durable metal housing; energy-efficient with low power consumption; auto MDI/MDIX eliminates the need for crossover cables; supports jumbo frames up to 9KB for improved performance.

Suitable for

• Home networks requiring additional wired connections
• Small office environments where noise reduction is important
• Desktop use where space is limited
• Connecting multiple devices such as computers, printers, and game consoles

Key specifications

• 3 x 10/100/1000 Mbps Gigabit Ethernet ports
• Unmanaged switch type
• Switching capacity: 6 Gbps
• Forwarding rate: 4.46 Mpps
• MAC address table: 2K entries
• Buffer memory: 512 Kbit
• Jumbo frame support: up to 9KB
• Fanless design
• Auto MDI/MDIX on all ports
• External power supply: DC 5V / 0.6A
• Max power consumption: 2.5 W
• LED indicators: Power, Link/Activity per port
• Housing material: Metal
• Mounting type: Desktop
• Operating temperature: 0°C to 40°C
• Operating humidity: 10% to 90% non-condensing
• Network standards: IEEE 802.3, 802.3u, 802.3ab, 802.3x

Recommendations

For a reliable and silent network expansion, the ALLNET ALL-NS1003 offers essential Gigabit connectivity in a compact metal chassis. Ideal for users who need a simple, no-fuss switch without compromising on performance.
