ALLNET MSR ALL3500 conjunto de fichas de substituição de relé Phoenix, 4 unid. (verde)

The ALLNET MSR ALL3500 Phoenix Relay Replacement Plug Set is a genuine accessory designed for the ALLNET ALL3500 MSR IP Sensor Server. This set includes four Phoenix Contact compatible relay replacement plugs, each featuring a 2-pin pluggable screw terminal for secure and reliable connections. Ideal for connecting external loads and devices to the ALL3500 MSR relay outputs, these plugs ensure easy installation and maintenance.

Advantages

High-quality construction with polyamide housing and tin-plated copper alloy contacts ensures durability and excellent conductivity. The screw connection method provides a firm and vibration-resistant termination for solid or stranded wires from 0.2 to 2.5 mm². Rated for up to 12 A and 320 V, these plugs are suitable for a wide range of industrial applications.

Suitable for

• ALLNET ALL3500 MSR IP Sensor Server
• Connecting external relays, actuators, or loads
• Industrial automation and building management systems

Key specifications

• Product Type: Relay Replacement Plug
• Compatibility: ALLNET ALL3500 MSR IP Sensor Server
• Number of Plugs: 4 (Set of 4)
• Connector Type: Pluggable Screw Terminal
• Number of Pins per Plug: 2-pin
• Terminal Connection Method: Screw Connection
• Manufacturer Standard: Phoenix Contact Compatible
• Recommended Wire Gauge (Solid): 0.2 - 2.5 mm²
• Recommended Wire Gauge (Stranded): 0.2 - 2.5 mm²
• Rated Current (Max): 12 A
• Rated Voltage (Max): 320 V (III/2)
• Pitch: 5.08 mm
• Color: Green
• Housing Material: Polyamide (PA)
• Operating Temperature Range: -40°C to +100°C
• Application: Connecting external loads/devices to ALL3500 MSR relay outputs
• Mounting Type: Plug-in
• Insulation Material: PA (Polyamide)
• Contact Material: Copper alloy (tin-plated)

Recommendations

For optimal performance, use with ALLNET ALL3500 MSR IP Sensor Server. Ensure wires are properly stripped and securely tightened in the screw terminals. Suitable for indoor use only.
