ALPEN-MAYKESTAG Alpen Pro TM 6 amplificador matriz de áudio multi-zona (2-3-4-5-6-8 zonas)

The ALPEN-MAYKESTAG Alpen Pro TM 6 is a professional multi-zone audio matrix amplifier designed for distributed audio systems in commercial and residential installations. It offers 6 independent zones with flexible input-to-output routing, allowing any of the 8 stereo RCA inputs to be assigned to any zone. Each zone delivers 2 x 60W RMS into 8 Ohms, with independent bass, treble, balance, and volume control via DSP. The amplifier is rack-mountable (2U) and features comprehensive control options including RS-232, Ethernet (IP), IR remote, and front panel LCD. Built-in protection circuits ensure reliable operation.

Advantages

• 6 independent zones with individual DSP control
• Any input to any output matrix switching
• High-quality audio with low THD (<0.05%) and high SNR (>90 dB)
• Versatile control: RS-232, Ethernet, IR, front panel
• Rack-mountable 2U design for professional integration

Suitable for

• Commercial audio distribution (restaurants, retail, offices)
• Multi-room residential audio systems
• Background music and paging systems
• Custom installation projects

Key specifications

• Number of Zones: 6
• Audio Inputs: 8x Stereo RCA (L/R)
• Audio Outputs: 6x Stereo Speaker Outputs, 6x Stereo RCA Pre-outs
• Output Power per Zone: 2 x 60W @ 8 Ohms (RMS)
• Frequency Response: 20 Hz - 20 kHz (+/- 0.5 dB)
• THD: < 0.05% (1 kHz, 1W)
• SNR: > 90 dB
• Input Sensitivity: 200mV
• Input Impedance: 47 kOhms
• Output Impedance: 4-16 Ohms (Speaker Outputs)
• Control Interfaces: RS-232, Ethernet (IP Control), IR Remote, Front Panel
• DSP Features: Independent Bass/Treble, Balance, Volume per zone
• Rack Mountable: Yes (2U)
• Power Supply: AC 100-240V, 50/60Hz
• Display: Front Panel LCD
• Protection: Overload, Short Circuit, Over-temperature
• Cooling: Fan-assisted

Recommendations

For optimal performance, use quality shielded RCA cables and 8 Ohm speakers. The amplifier can be integrated with automation systems via IP control. Ensure proper ventilation for fan cooling.
