Contacto auxiliar Schneider Electric LC1D65AP7 para contactores, contacto de corrente alternada 230 V, multicor

Schneider Electric LC1D65AP7 auxiliary contact designed for integration with compatible contactors to provide supplementary switching and signaling functions. The accessory includes an AC auxiliary contact rated for 230 V and a multicolour housing that aids visual identification of contact status. It is intended for control circuits and status indication in industrial and building automation environments where reliable auxiliary switching is required alongside the main contactor.

Advantages

The auxiliary contact offers a compact form factor for mounting on the associated contactor, enabling space-efficient installation. The 230 V AC rated contact supports standard control voltage schemes, and the multicolour housing improves operational clarity for maintenance and monitoring. Constructed to Schneider Electric quality standards, it provides consistent electrical switching performance for auxiliary circuits.

Suitable for

• Providing auxiliary switching for motor control circuits
• Signalling contactor status to control panels and PLCs
• Integration into building automation for indication and interlocking
• Use in industrial control cabinets and distribution panels

Key specifications

• Auxiliary contact type: AC auxiliary contact
• Nominal operating voltage (auxiliary): 230 V AC
• Housing: multicolour for status identification
• Mounting: designed for attachment to compatible contactors
• Function: provides secondary switching and signaling circuits

How to use

Attach the auxiliary contact to the compatible contactor following the contactor manufacturer's mechanical and electrical connection instructions. Connect the auxiliary contact terminals to the desired control or signaling circuit, observing correct voltage rating and wiring polarity where applicable. Verify secure fastening and perform an operational check by energizing the main contactor and confirming the auxiliary contact changes state as expected.

Recommendations

Ensure wiring and installation are carried out by a qualified electrician. Confirm compatibility with the main contactor model and observe local electrical codes. Regularly inspect connections for tightness and signs of wear to maintain reliable auxiliary switching and indication.
