AWTOOLS Suporte Angular Vertical / Horizontal 50x80cm | Esquadro de Precisão em Aço

Unlike ordinary carpenter's squares that offer only a single reference edge, the AWTOOLS 502652 combines a true 90-degree reference with dual vertical and horizontal measurement capability. Its 800 mm long arm and 500 mm short arm are precision ground from high-grade steel, then laser-etched with metric scales in both centimetres and millimetres. The 40 mm wide, 3 mm thick blade resists flexing during layout, while the anti-corrosion coating keeps the tool accurate in damp workshops or on outdoor job sites.

Highlights

• True 90-degree square for reliable vertical and horizontal alignment
• Long arm: 800 mm (80 cm); short arm: 500 mm (50 cm)
• High-grade steel construction with precision ground edges
• Engraved metric scale in cm and mm – no fading or peeling
• Anti-corrosion finish for long-term durability
• Integrated hanging hole for easy storage

In daily use

Framing a wall, checking cabinet corners, or marking sheet goods becomes effortless with this bracket as a solid reference edge. The wide 40 mm blade sits flat against the workpiece, and the 3 mm thickness prevents bending under pressure. Because the markings are laser-etched into the steel, they remain legible even after years of contact with pencils, sawdust, and job site grit. The metallic grey coating not only protects against rust but also makes the tool easy to spot among other layout tools.

Full specifications

• Tool type: Carpenter's angle bracket / square
• Measurement capability: Vertical and horizontal angles
• Long arm length: 800 mm (80 cm)
• Short arm length: 500 mm (50 cm)
• Material: High-grade steel
• Measurement scale: Metric (cm, mm)
• Angle accuracy: True 90-degree (square)
• Blade width: 40 mm
• Blade thickness: 3 mm
• Markings: Engraved / laser-etched
• Finish: Anti-corrosion coating
• Primary application: Woodworking, carpentry, construction, DIY
• Edge type: Precision ground edges
• Durability: High strength, wear-resistant
• Storage feature: Integrated hanging hole
• Colour: Metallic grey
• Units of measurement: Centimetres, millimetres

Final note

Built to withstand the demands of daily professional use, the AWTOOLS angle bracket is a reliable companion for precise layout work in any environment.
