Base de relé Siemens LZS:RT78726 de 4 polos para SIRIUS 3TG10, terminais de parafuso, montagem em calha DIN/parafuso, cinzento

Rated insulation voltage 250 V AC/DC and impulse withstand 4 kV — the Siemens LZS:RT78726 plug-in base provides a robust connection for 4-pole SIRIUS 3TG10 miniature control relays.

Overview

This relay socket accepts 4-pole SIRIUS 3TG10 miniature control relays. It features 12 screw terminals and supports DIN rail (35 mm) or screw mounting. The thermoplastic housing is grey.

What stands out

• 12 screw terminals for secure wiring
• DIN rail or screw mounting flexibility
• Operating temperature range -25 to +70 °C
• IP20 terminal protection

Technical details

• Compatible relay series: SIRIUS 3TG10
• Number of relay poles: 4
• Terminal type: Screw
• Number of terminals: 12
• Rated insulation voltage: 250 V AC/DC
• Rated impulse withstand voltage: 4 kV
• Operating temperature: -25 to +70 °C
• Storage temperature: -40 to +80 °C
• Connection cross-section solid: 0.5 - 2.5 mm²
• Connection cross-section stranded with ferrule: 0.5 - 1.5 mm²
• Tightening torque: 0.8 - 1.2 Nm
• Pollution degree: 3
• Material: Thermoplastic
• Colour: Grey

Our verdict

A reliable socket for industrial control applications, offering flexible mounting and a wide temperature range.
