BCS BCS-05506MIR Leitor de códigos de barras fixo, laser, RS-232/RS-485, IP65, cabo de 6m

The BCS BCS-05506MIR is a high-performance fixed-mount barcode scanner designed for industrial automation and logistics applications. Featuring advanced laser scanning technology with an oscillating mirror, it delivers reliable 1D barcode reading at distances up to 600 mm. Its rugged aluminum housing and IP65 rating ensure durability in harsh environments.

Advantages

With a scan rate of 500-1000 scans per second and a minimum resolution of 0.15 mm (6 mil), the BCS-05506MIR provides fast and accurate scanning of even small or damaged barcodes. The integrated 6-meter cable simplifies installation, while the RS-232 and RS-485 interfaces offer flexible connectivity for industrial systems. Configuration via Datalogic Genius software allows easy customization.

Suitable for

• Automated production lines and conveyor systems
• Warehouse and distribution center scanning stations
• Sorting and tracking applications in logistics
• Industrial environments requiring IP65 protection

Key specifications

• Scanning Technology: Laser (VLD 650 nm)
• Scan Pattern: Oscillating Mirror
• Scan Rate: 500-1000 scans/second
• Max. Reading Distance: Up to 600 mm (23.6 in)
• Minimum Resolution: 0.15 mm (6 mil)
• Supported Symbologies: 1D (Code 39, Code 128, EAN/UPC, Interleaved 2 of 5, etc.)
• Connectivity: RS-232, RS-485
• Input Voltage: 10-30 VDC
• Power Consumption: Max 3 W
• IP Rating: IP65
• Housing Material: Aluminum
• Cable Length: 6 m (integrated)
• Indicators: 2 LEDs (Power, Good Read)
• Configuration Software: Datalogic Genius

Recommendations

For optimal performance, mount the scanner at the recommended distance and angle for your specific barcode size and application. Use Datalogic Genius software to fine-tune settings. Ensure the power supply meets the 10-30 VDC requirement.
