BlueOptics 02313NUG Transceptor QSFP28 100GBASE-LR4 compatível, LC Duplex, 10 km, SMF 02313NUG-BO

Data center and enterprise networks demand 100G links that can span long distances without signal regeneration. The BlueOptics 02313NUG-BO QSFP28 transceiver solves this by delivering 100GBASE-LR4 connectivity over single-mode fiber up to 10 km. It is engineered for compatibility with the BlueOptics 02313NUG reference, ensuring seamless integration in existing optical infrastructures.

Who is it for

Network architects and IT administrators building high-capacity backbone links between data centers, campus networks, or enterprise core switches. It suits environments where 100G throughput must travel beyond the reach of multimode fiber, and where hot-swappable, standards-based optics are required.

Main features

• QSFP28 form factor with LC duplex connector for single-mode fiber
• 100GBASE-LR4 Ethernet standard, 1310 nm wavelength, 10 km reach
• Digital diagnostics monitoring (DDM/DOM) for real-time link health
• Hot-pluggable, full-duplex operation with < 4.5 W power consumption
• Commercial temperature range 0°C to 70°C

Specifications

• Data rate: 100 Gbps
• Connector: LC Duplex
• Fiber type: Single-mode (SMF)
• Transmitter: DFB laser; Receiver: PIN photodetector
• Electrical interface: 4x 25Gbps (CAUI-4)
• Supply voltage: 3.3V

Tips

Verify switch compatibility with the 02313NUG reference before deployment. Use OS2 single-mode patch cables with LC connectors. Enable DDM monitoring in the network management system to track optical power and temperature.
