BlueOptics Rabbit BO15C4931620D-WR compatível BlueOptics SFP BO15C4931620D-WR

Delivering 1.25 Gbps over distances up to 10 km on a single-mode fiber, the BlueOptics Rabbit BO15C4931620D-WR SFP transceiver is engineered for reliable Gigabit Ethernet connectivity with a 1310 nm DFB laser and DDM diagnostics.

Overview

The BlueOptics Rabbit BO15C4931620D-WR is a hot-swappable SFP transceiver module compliant with the Multi-Source Agreement (MSA). It operates at a wavelength of 1310 nm, supporting 1000BASE-LX/LH Gigabit Ethernet over single-mode fiber (SMF) with an LC duplex connector. The module supports Digital Diagnostic Monitoring (DDM/DOM), enabling real-time monitoring of critical parameters such as optical output power, input power, temperature, and supply voltage.

What stands out

• High-performance DFB laser transmitter and PIN photodiode receiver ensure stable signal integrity over 10 km.
• Hot-swappable design allows for installation and removal without powering down the host system.
• DDM/DOM support provides proactive network monitoring and fault isolation.
• Low power consumption of less than 1 W contributes to energy efficiency.
• Commercial operating temperature range (0°C to 70°C) suits standard enterprise environments.

Technical details

• Form Factor: SFP (Small Form-Factor Pluggable)
• Data Rate: 1.25 Gbps
• Wavelength: 1310 nm
• Max Transmission Distance: 10 km
• Fiber Type: Single-Mode Fiber (SMF)
• Connector Type: LC Duplex
• DDM/DOM Support: Yes
• Operating Temperature Range: 0°C to 70°C
• Power Supply Voltage: 3.3 V
• Hot-Swappable: Yes
• Compliance: MSA Compliant
• Application: Gigabit Ethernet (1000BASE-LX/LH)
• Transmitter Type: DFB Laser
• Receiver Type: PIN Photodiode
• Power Consumption: < 1 W
• Duplex Mode: Full Duplex

Our verdict

A dependable and cost-effective SFP transceiver for extending Gigabit Ethernet over single-mode fiber, with the added benefit of digital diagnostics for network management.
