BlueOptics Transceptor QSFP+ 40GBASE-LR4 para Juniper 740-062254, 10km, LC Duplex, monomodo

BlueOptics QSFP+ transceiver delivers 40 Gigabit Ethernet over single-mode fiber for Juniper 740-062254 compatible networks. It supports 40GBASE-LR4 with four LAN-WDM wavelengths (1271nm, 1291nm, 1311nm, 1331nm) and reaches up to 10 km over OS2 fiber. The module is hot-pluggable and includes digital diagnostics monitoring (DDM/DOM) for real-time performance tracking.

Advantages

This transceiver provides high-speed 40G connectivity for data centers and enterprise backbones. It uses DFB lasers and consumes less than 3.5 W, ensuring efficient operation. The LC duplex connector ensures easy installation, and the commercial temperature range (0°C to 70°C) suits standard data center environments.

Suitable for

• 40 Gigabit Ethernet links in switches, routers, and storage systems
• Data center interconnect and enterprise networking
• Fibre Channel and SONET/SDH applications
• Telecommunications infrastructure

Key specifications

• Form Factor: QSFP+
• Data Rate: 40 Gbps
• Transceiver Type: 40GBASE-LR4
• Wavelength: 1271nm, 1291nm, 1311nm, 1331nm
• Max Distance: 10 km
• Connector: LC Duplex
• Fiber Type: Single-mode (SMF)
• DDM/DOM: Yes
• Hot-Pluggable: Yes
• Power Consumption: < 3.5 W
• Operating Temperature: 0°C to 70°C
• Voltage: 3.3 V
• MTBF: > 500,000 hours

Recommendations

For optimal performance, use OS2 single-mode fiber cables with LC connectors. Verify compatibility with Juniper equipment requiring 740-062254 transceivers.
