Braçadeira de cabos Rittal CM 5001.080, aço, superfície metálica, largura 499 mm

Rittal CM 5001.080 is a steel cable clamp with a metallic finish and a width of 499 mm, designed for securing and routing cable bundles inside electrical enclosures and control panels. The clamp provides mechanical strain relief at cable entry points and helps maintain organized wiring runs in industrial and commercial installations. The clamp rail length matches the width of the mounting plate and the included mounting bracket supports three different installation positions on the mounting plate.

Advantages

The steel construction with a metallic finish delivers durable mechanical support and resistance to wear in demanding environments. A tailored rail length that corresponds to the mounting plate width simplifies installation and ensures a proper fit. The supplied mounting bracket offers flexibility by supporting three different installation situations, enabling reliable strain relief at cable entry points and adaptable routing of cable bundles.

Suitable for

Key specifications

How to use

Position the cable clamp rail across the mounting plate so the 499 mm width aligns with the plate edges. Use the supplied mounting bracket to select the appropriate installation position that fits your cabinet layout and secure the bracket and clamp to the mounting plate using suitable fasteners. Route cable bundles into the clamp and tighten or secure them in place to provide strain relief and maintain organized routing. Verify that cables are held without sharp bends and that the clamp does not compress or damage insulation.

Recommendations

Choose fasteners and torque settings appropriate for the mounting plate material and the cabinet application. Inspect cable routing after installation to ensure strain relief is effective and allow access for maintenance. For high-vibration environments, periodically check the clamp and bracket tightness.
