BROADCOM módulo transceptor SFP+ SFBR-709SMZ-DC1

High-speed data centers and enterprise networks often face bottlenecks when linking switches, servers, and storage over short distances. The Broadcom SFBR-709SMZ-DC1 SFP+ transceiver solves this by delivering reliable 10 Gigabit Ethernet connectivity over multimode fiber, ensuring smooth traffic for bandwidth-intensive applications.

Who is it for

Network engineers and IT managers upgrading to 10G infrastructure in data centers, campus backbones, or high-performance computing clusters. Ideal for connections up to 300 meters over OM3 multimode fiber, or 82 meters over OM2, without the cost of single-mode optics.

Main features

• Hot-pluggable SFP+ form factor for easy installation and replacement without downtime.
• Supports 10GBASE-SR standard, compliant with IEEE 802.3ae, SFF-8431, and SFF-8432.
• 850nm VCSEL laser optimized for multimode fiber, with LC duplex connector.
• Digital diagnostics monitoring (DDM/DOM) for real-time performance tracking.
• Low power consumption under 1W, reducing energy costs in dense deployments.
• Wide operating temperature range from 0°C to 70°C for reliable operation.

Specifications

• Data rate: 10 Gbps
• Wavelength: 850 nm
• Reach: 300 m on OM3 MMF, 82 m on OM2 MMF
• Connector: LC duplex
• Transmitter output power: -6.5 to -0.5 dBm
• Receiver sensitivity: < -11.1 dBm
• Power supply: +3.3V
• Operating temperature: 0°C to 70°C
• Storage temperature: -40°C to 85°C
• RoHS compliant

Tips

For best performance, pair with OM3 or OM4 multimode fiber. Use the digital diagnostics to monitor optical power and temperature, and ensure proper cleaning of LC connectors before installation to avoid signal loss.
