Brüder Mannesmann Sargento em F 910-500, 500 mm de abertura, 120 mm de alcance, barra de aço, mordentes em ferro fundido maleável, azul/prateado

Securing workpieces firmly during gluing, sawing, or welding can be a challenge without the right clamping tool. The Brüder Mannesmann F-Clamp 910-500 provides a reliable solution with its 500 mm clamping range and robust construction. The high-quality profiled steel bar and malleable cast iron jaws deliver the strength needed for demanding tasks, while the ergonomic wooden handle ensures comfortable operation. Protective plastic jaw caps prevent damage to delicate surfaces, making this clamp suitable for a wide range of applications.

Who is it for

This clamp is ideal for woodworkers, metalworkers, and DIY enthusiasts who need a dependable clamping tool for assembly, gluing, or holding workpieces securely in place.

Main features

• Clamping range: 500 mm
• Throat depth: 120 mm
• Bar material: High-quality profiled steel, galvanized
• Jaw material: Malleable cast iron, powder-coated blue
• Handle: Ergonomic wooden handle
• Spindle: Steel with trapezoidal thread
• Protective plastic jaw caps included
• Conforms to DIN 5117

Specifications

• Clamp type: F-clamp (screw clamp)
• Clamping range: 500 mm
• Throat depth: 120 mm
• Bar profile dimensions: approx. 30 x 8 mm
• Bar finish: Galvanized
• Jaw finish: Powder-coated blue
• Handle material: Wood
• Spindle thread type: Trapezoidal
• Quick release mechanism: No
• Jaw swivel: No
• Application: Woodworking, metalworking, general assembly
• Colour: Silver bar, blue jaws

Tips

To avoid marring soft woods or finished surfaces, ensure the protective jaw caps are in place before applying pressure. For maximum stability, position the clamp so that the fixed jaw is against the workpiece and the sliding jaw is tightened evenly.
