Busch-Jaeger módulo de entrada de áudio A251381A-S-03 para Busch-AudioWorld® (2TMA220160X0008)

Integrate your external stereo audio sources into the Busch-AudioWorld® system with the Busch-Jaeger Audio Input Module A251381A-S-03. This module allows connection of devices such as MP3 players, smartphones, or CD players via a compatible cover plate with 3.5mm jack or RCA inputs. It is designed for flush mounting in standard flush-mount boxes, making it ideal for residential and commercial installations where seamless audio integration is required.

Key specifications

• Product type: Audio input module
• System compatibility: Busch-AudioWorld®
• Input signal type: Stereo analog audio
• Connection to front plate: Plug-in connector for Busch-AudioWorld® cover plates
• System bus connection: Screw terminals
• Mounting type: Flush-mounted
• Installation depth: Approx. 32 mm
• Power supply: Via Busch-AudioWorld® bus system
• Number of audio channels: 2 (Stereo)
• Output to bus: Digital audio signal
• Material: High-quality plastic
• Colour: Black/Grey
• Series: Busch-AudioWorld®
• Operating temperature range: 5°C to 45°C
• Storage temperature range: -20°C to 70°C
• Relative humidity: 5% to 95% (non-condensing)

Why choose it

This module provides a reliable and straightforward way to bring external audio sources into your Busch-AudioWorld® setup. Its plug-in connector ensures easy installation with compatible cover plates, while the screw terminals offer a secure bus connection. The flush-mounted design keeps the installation neat and unobtrusive.

Ideal use cases

• Connecting a smartphone or MP3 player to a whole-home audio system
• Integrating a CD player or other analog audio source in a residential setup
• Adding audio input capability to a Busch-AudioWorld® installation in offices or commercial spaces

Good to know

The module requires a Busch-AudioWorld® cover plate with audio input (e.g., 3.5mm jack or RCA) for connecting external devices. It is powered directly from the Busch-AudioWorld® bus system, eliminating the need for a separate power supply.
