BUSCH-JAEGER Tomada encastrada 0471-0-0037 SCHUKO 16A 250V preto

The BUSCH-JAEGER 0471-0-0037 is a flush-mounted SCHUKO socket designed for integration into furniture, devices, and workbenches where a discreet power connection is needed. Unlike surface-mounted alternatives, this built-in unit sits nearly flush with the mounting surface, keeping the installation clean and unobtrusive.

Highlights

• SCHUKO (Type F) socket, 2-pole with earth
• Rated for 16 A at 250 V AC, 50/60 Hz
• Flush-mounted design for built-in applications
• Screw terminals accept up to 2.5 mm² conductors
• Thermoplastic housing in black
• Halogen-free material

In daily use

This socket provides a reliable power point in custom furniture, workstations, or equipment housings. The screw terminals ensure a secure connection, and the compact 50 x 50 mm front plate fits standard cut-outs. With an installation depth of 28 mm, it suits many panel thicknesses.

Full specifications

• Socket type: SCHUKO (Type F)
• Configuration: 2-pole + earth (PE)
• Rated current: 16 A
• Rated voltage: 250 V AC
• Frequency: 50/60 Hz
• Mounting type: Flush-mounted / built-in
• Connection type: Screw terminals
• Material: Thermoplastic (PC/ABS)
• Colour: Black
• Protection class: IP20
• Installation depth: 28 mm
• Outer dimensions (front plate): 50 x 50 mm
• Terminal capacity: max. 2.5 mm²
• Operating temperature: -5 °C to +40 °C
• Halogen-free: Yes
• Number of sockets: 1
• Orientation: Straight

Final note

Designed for built-in use, the BUSCH-JAEGER 0471-0-0037 delivers a dependable SCHUKO connection in a compact, halogen-free housing.
