BVV-P 2x1,5 mm² cabo plano 100m branco

This BVV-P flat power cable is designed for fixed installations in general wiring and lighting circuits. With 2 solid copper conductors of 1.5 mm² each, it provides reliable power distribution in residential and commercial buildings. The PVC insulation and sheath offer flame retardancy and moisture resistance, ensuring safe operation in dry or damp environments.

Advantages

Flat profile saves space and simplifies routing along walls or under floors. Flame retardant PVC sheath self-extinguishes to reduce fire spread. Solid copper conductors ensure low resistance and stable connections. Rated for 300/500 V and 19 A current carrying capacity, suitable for lighting and small appliance circuits.

Suitable for

• Fixed wiring in residential and commercial buildings
• Lighting circuits and general power distribution
• Indoor installations in dry or damp locations

Key specifications

• Cable type: BVV-P (PVC insulated, PVC sheathed, flat)
• Number of cores: 2
• Conductor cross-section: 1.5 mm²
• Conductor material: Copper (solid)
• Insulation: PVC
• Sheath: PVC
• Cable shape: Flat
• Colour: White
• Length: 100 m
• Rated voltage: 300/500 V
• Max. operating temperature: +70°C
• Min. operating temperature: -40°C
• Flame retardant: Yes (self-extinguishing)
• Standard: GOST 31996-2012
• Current carrying capacity: 19 A (in air)
• Outer dimensions (approx.): 4.5 x 7.5 mm
• Core identification: Brown, Blue

Recommendations

For indoor fixed installations only. Ensure compliance with local electrical codes. Use appropriate connectors and junction boxes. Not suitable for outdoor or direct burial applications.
