Cabo DAC QSFP28 BlueOptics Compatível com Lenovo 00MP520 BlueLAN SC282801L1M30, 100GBASE-CR4, InfiniBand EDR, 30AWG, 1 metro (00MP520-BL)

The BlueOptics 00MP520-BL is a high-performance, cost-effective direct attach copper cable (DAC) designed to be fully compatible with Lenovo 00MP520 transceivers. It provides reliable 100 Gbps connectivity for Ethernet and InfiniBand EDR networks, ideal for data center and HPC environments.

Advantages

This passive DAC cable offers low power consumption (<0.1W), hot-swappable convenience, and robust construction with 30 AWG copper and PVC jacket. It ensures seamless integration with Lenovo equipment while reducing costs compared to OEM alternatives.

Suitable for

• Data center interconnects
• High-performance computing (HPC) clusters
• Enterprise networking
• Lenovo server and switch deployments

Key specifications

• Cable Type: Direct Attach Cable (DAC), Passive
• Connector: QSFP28 to QSFP28
• Data Rate: 100 Gbps (Ethernet and InfiniBand EDR)
• Length: 1 Meter (3.3 ft)
• Wire Gauge: 30 AWG
• Material: Copper, PVC jacket
• Compliance: RoHS, CE, FCC
• Operating Temperature: 0°C to 70°C

Recommendations

For optimal performance, ensure your network equipment supports QSFP28 interfaces and 100GBASE-CR4 or InfiniBand EDR standards. This cable is a direct replacement for Lenovo 00MP520.
