Cabo de fibra ótica DeLOCK ficha macho CS para LC duplex OS2 1 m

The DeLOCK optical fiber cable with a CS male to LC Duplex connector is a 1 m singlemode cable compliant with G657A2 / OS2 standards. It is designed for full duplex data transmission and has a 9 µm core diameter, making it suitable for high-density installations and data centre cabling where space-saving connectors are required. The cable is supplied in blue/yellow colour variants and supports reliable long-distance optical transmission with low attenuation.

Advantages

The CS connector offers a smaller form factor compared with LC Duplex connectors, enabling higher packing density in racks and patch panels. The push-pull tab facilitates easy insertion and removal of the connector. The singlemode OS2 / G657A2 fibre minimises signal loss and maintains transmission quality over typical singlemode distances.

Suitable for

Key specifications

How to use

Align the CS male connector with the corresponding CS female port on the transceiver or panel and push until the connector locks using the push-pull tab. For the LC Duplex end, align both LC ferrules with the LC receptacle and insert until secure. Ensure that connectors and ports are clean before connection to avoid contamination and signal loss. Route the cable to avoid sharp bends and secure it in fibre management accessories to prevent strain.

Recommendations

Use appropriate fibre cleaning tools before connecting, maintain minimum bend radius as specified by the manufacturer, and store spare connectors with protective caps to prevent contamination and damage.
