Cabo de patch Telegärtner Cat 6A S/FTP, PiMF, LSZH, RJ45 para RJ45 angular 90°, 5 m, vermelho L00003A0123

This Telegärtner patch cable stands out with its one-sided 90° angled RJ45 connector, which allows tidy connections in tight spaces behind desks or patch panels. The S/FTP shielding with PiMF (pairs in metal foil) ensures reliable 10 Gigabit Ethernet performance even in electromagnetically noisy environments. The halogen-free LSZH jacket makes it suitable for use in public buildings and areas with strict fire safety requirements.

Highlights

• Cat 6A performance for 10GBASE-T networks up to 500 MHz
• S/FTP shielding: overall braid plus foil around each twisted pair (PiMF)
• One straight RJ45 plug and one 90° angled RJ45 plug
• Halogen-free LSZH jacket, red colour, 5 m length
• Supports Power over Ethernet (PoE, PoE+, PoE++)

In daily use

The angled connector reduces the required clearance behind connected equipment, preventing excessive bending of the cable. The stranded copper conductors keep the cable flexible for frequent re-patching, while the robust die-cast connectors withstand regular handling. The red jacket provides clear identification in crowded cable runs.

Full specifications

• Cable standard: Cat 6A (Category 6A)
• Shielding type: S/FTP (Screened Foiled Twisted Pair)
• Pair shielding: PiMF (Pairs in Metal Foil)
• Data rate support: 10 Gigabit Ethernet (10GbE)
• Length: 5.0 m
• Colour: Red
• Connector A: RJ45 male, straight
• Connector B: RJ45 male, 90° angled
• Jacket material: LSZH (Low Smoke Zero Halogen)
• Conductor material: Copper
• Conductor type: Stranded
• Wiring scheme: TIA/EIA-568B
• Impedance: 100 Ohm
• PoE support: PoE, PoE+, PoE++ (4PPoE)
• Application: Local Area Network (LAN)
• Halogen-free: Yes

Final note

Telegärtner's precision-manufactured connectors and high-quality materials ensure long-term signal integrity, making this cable a reliable choice for professional network installations.
