Cabo de patch Telegärtner Cat.6A S/FTP RJ45 0,25m branco

The Telegärtner H02050A0327 is a high-performance Cat.6A S/FTP (PIMF) patch cable designed for reliable 10 Gigabit Ethernet connections. With a length of 0.25 meters and a white LSZH jacket, this cable is ideal for short-distance, high-speed network links in data centers, server rooms, and professional IT environments.

Advantages

This patch cable offers exceptional signal integrity and noise protection thanks to its S/FTP shielding (overall braid and foil per pair). The LSZH (Low Smoke Zero Halogen) jacket ensures safety in enclosed spaces by reducing toxic fumes and smoke in case of fire. Gold-plated contacts (50µm) provide corrosion resistance and reliable connectivity.

Suitable for

• Connecting network devices in 10 Gigabit Ethernet networks
• Data center patching between switches, servers, and patch panels
• High-frequency applications requiring up to 500 MHz bandwidth
• Power over Ethernet (PoE, PoE+, 4PPoE/PoE++) devices

Key specifications

• Cable Standard: Cat.6A (Class EA)
• Shielding: S/FTP (Screened/Foiled Twisted Pair)
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Length: 0.25 m
• Colour: White
• Connectors: RJ45 (8P8C) both ends
• Data Transfer Rate: Up to 10 Gbps
• Frequency Bandwidth: Up to 500 MHz
• Wiring Scheme: TIA/EIA 568B
• Conductor: Copper stranded, AWG 26/7
• Connector Plating: Gold (50µm)
• Flame Retardancy: IEC 60332-1-2
• Halogen Free: Yes
• PoE Support: PoE, PoE+, 4PPoE/PoE++
• Outer Diameter: approx. 6.2 mm
• Operating Temperature: -20°C to +60°C

Recommendations

For optimal performance, use this cable with Cat.6A compatible devices and ensure proper termination. Ideal for short patch connections where space is limited.
