Cabo de patch Telegärtner Cat.7A S/FTP, 5 m, LSZH, cinzento, 10 Gbps, RJ45 100017395

With a bandwidth of 1000 MHz and support for 10 Gigabit Ethernet, this Cat.7A patch cable delivers exceptional performance for high-speed networking. The S/FTP shielding with individually foil-wrapped pairs and an overall braid ensures superior protection against crosstalk and EMI, making it ideal for data centers and industrial environments.

Overview

The Telegärtner L82103A0000 is a 5-meter Cat.7A patch cable engineered for reliable 10GBase-T connections. It features gold-plated RJ45 connectors, stranded AWG 26/7 copper conductors, and a durable LSZH jacket that is halogen-free and flame retardant. Operating temperature range spans from -40 to 85 °C, suitable for harsh conditions.

What stands out

• Cat.7A (Class FA) performance up to 1000 MHz
• S/FTP shielding: PiMF and overall braid
• Supports PoE, PoE+, and 4PPoE (IEEE 802.3af/at/bt)
• LSZH jacket, halogen-free and flame retardant (IEC 60332-1-2)
• Wide operating temperature range: -40 to 85 °C
• Molded snagless boots for durability

Technical details

• Length: 5 m
• Colour: Grey (RAL 7035)
• Connector type: RJ45 (8P8C) on both ends, gold-plated contacts (50µ")
• Conductor: Bare copper, AWG 26/7 stranded
• Outer diameter: 6.2 mm
• Wiring standard: TIA/EIA 568B
• Standards compliance: ISO/IEC 11801, EN 50173, TIA/EIA-568-C.2

Our verdict

This cable combines top-tier Cat.7A performance with rugged construction, making it a reliable choice for demanding network installations where signal integrity and safety are paramount.
