Cabo de rede de fibra ótica GRAFENTHAL OS2 monomodo LC/UPC para LC/UPC duplex 1m amarelo

The GRAFENTHAL OS2 Single-Mode Fiber Optic Patch Cable is a high-performance, duplex patch cord designed for reliable data transmission in demanding network environments. With LC/UPC connectors on both ends and a 1-meter length, this cable ensures low insertion loss and high return loss, making it ideal for high-speed networks, data centers, and FTTx applications. The LSZH (Low Smoke Zero Halogen) jacket provides enhanced safety in confined spaces.

Advantages

This fiber optic patch cable offers superior signal integrity with attenuation as low as 0.35 dB/km at 1310nm and 0.25 dB/km at 1550nm. The duplex LC/UPC connectors guarantee a secure connection and easy polarity management. The yellow color indicates OS2 single-mode fiber, simplifying identification in cable runs. LSZH jacket reduces toxic smoke and fumes in case of fire, making it suitable for indoor installations.

Suitable for

• Data centers and server rooms
• Local Area Networks (LAN) and Wide Area Networks (WAN)
• Fiber to the x (FTTx) deployments
• High-speed network equipment connections
• Telecommunications and CATV systems

Key specifications

• Cable Type: Fiber Optic Patch Cable
• Fiber Mode: Single-Mode (OS2)
• Connector Type: LC/UPC to LC/UPC, Duplex
• Fiber Core/Cladding: 9/125 µm
• Cable Length: 1 meter
• Jacket Material: LSZH (Low Smoke Zero Halogen)
• Cable Color: Yellow
• Insertion Loss: < 0.3 dB
• Return Loss: > 50 dB (UPC)
• Operating Temperature: -20°C to 70°C
• Minimum Bend Radius: 10 mm
• Compliance: RoHS, CE, TIA/EIA-568-C.3

Recommendations

For optimal performance, ensure connectors are clean before installation. This cable is compatible with all standard LC duplex ports. Pair with GRAFENTHAL patch panels and adapters for a complete structured cabling solution.
