Cabo Direct Attach BLUELAN compatível com Mellanox MCP1650-V003E26 QSFP56, 200GBASE-CR4, InfiniBand, 30AWG, 3 metros (MCP1650-V003E26-BL)

High-speed data centers and HPC clusters need reliable 200G interconnects without the cost and complexity of optical modules. This BLUELAN passive Direct Attach Cable (DAC) delivers exactly that: a 3-meter copper link that plugs directly into QSFP56 ports, supporting 200GBASE-CR4 and InfiniBand protocols. It eliminates the need for separate transceivers, reducing latency and power consumption while maintaining signal integrity over short distances.

Who is it for

Network engineers and system integrators deploying Mellanox switches, NICs, or servers in data centers, HPC environments, or enterprise racks. Ideal for top-of-rack to server connections where 200G throughput is required over short distances.

Main features

• 200 Gbps data rate with 200GBASE-CR4 standard
• QSFP56 to QSFP56 connectors, passive copper construction
• 30 AWG wire gauge for flexibility and performance
• Compatible with Mellanox MCP1650-V003E26 part number
• Hot-swappable, low power consumption (< 0.5W)
• 100 Ohm impedance for reliable signal transmission

Specifications

• Cable length: 3 Meter
• Data rate: 200 Gbps
• Standard: 200GBASE-CR4
• Connector type: QSFP56 (both ends)
• Wire gauge: 30 AWG
• Cable material: Copper
• Transceiver type: Passive
• Networking protocol: InfiniBand
• Form factor: QSFP56
• Application: High-Speed Data Interconnect, Data Center, HPC
• Hot-swappable: Yes
• Power consumption: < 0.5W
• Impedance: 100 Ohm

Tips

Ensure both connected devices have QSFP56 ports and support 200G speeds. For longer distances, consider active optical cables (AOCs) instead. Always verify compatibility with your specific Mellanox equipment model.
